Features
A mesh WiFi 6 system with five antennas to provide a super-fast network for large homes with 4K streaming and gaming demands. Suitable for internet access up to 2.5 Gbps.
- Provides uninterrupted Wi-Fi across the entire home (Up to 2100 Sq Ft per Bundle) – Ideal for 2-3 Bedroom Houses (Depends on the house structure)
- Seamless connectivity across the home where customers do not need to change Wifi networks
- High W-iFi speeds of up to 2402 Mbps
- Added Security secures users and protects against data breaches
- Network Agnostic so can be connected with any operator
- Packaging contains Mesh router pair (2 nodes). Both mesh can be managed and set up by the CUDY app
Â
Highlights
- 1.3 GHz Dual-Core CPU
- 4-Stream Dual-Band Wi-Fi 6
- 2402 Mbps + 574 Mbps Wi-Fi 1
- 200 Connected Devices 2
- Fast Roaming
- Cudy Mesh, VPN Server and Client
- Multi-Band Simultaneous Backhaul
- Cudy App, Cloud Control
Â
App Support
The Cudy App lets you set up, control, and monitor the AX3000 Mesh system directly from your smartphone. Enjoy quick installation, simple network management, and remote access for everyday convenience
Key Features
- Fast and guided setup
- Monitor and manage connected devices
- Add and control mesh nodes
- Share Wi-Fi via QR code
- LED on/off control
- Remote cloud access (supported models)
- Firmware updates and basic settings
Â
IOS and Android apps can be downloaded from below QR
Specifications
Hardware Specifications
|
Model Version |
M3000 2.0 |
|
|
CPU |
CPU Details |
1.3 GHz Dual-Core, ARM Cortex-A53 |
|
Memory/Storage |
Flash/ROM |
128 MB (1 Gbit) NAND |
|
DDR/RAM |
256 MB (2 Gbit) DDR3 |
|
|
Wireless |
5 GHz Wi-Fi Speed |
2402 Mbps |
|
2.4 GHz Wi-Fi Speed |
574 Mbps |
|
|
5 GHz Wi-Fi Streams |
2T2R (2×2 MIMO) |
|
|
2.4 GHz Wi-Fi Streams |
2T2R (2×2 MIMO) |
|
|
Wi-Fi Antennas |
5× Internal |
|
|
FEM or PA/LNA |
5 GHz: 3× Internal |
|
|
2.4 GHz: 2× Internal |
||
|
Beamforming |
TRUE |
|
|
Range Performance |
Max: 220 m (722 ft) |
|
|
Tested in open-space environments with minimal interference. Actual WiFi range may vary depending on layout and wall materials. Refer to the Wall Performance specifications for placement suggestions. |
||
|
Wall Performance |
Two wooden walls with thickness < 10 cm (4'') |
|
|
One concrete wall with thickness < 20 cm (7'') or two concrete walls with thickness < 10 cm (4'') |
||
|
Indoor Coverage Reference |
2 Pack: 200 m² (2100 sq ft) |
|
|
Applied to wireless backhaul situation. Place in the center of each floor, with a maximum of three obstacles to each room. |
||
|
Interfaces |
2.5G RJ45 Ports |
1 |
|
Gigabit RJ45 Ports |
1 |
|
|
Ethernet Notes |
The 2.5G port is the WAN port, the Gigabit port is LAN port |
|
|
LED |
System |
|
|
Speed/Link/ACT of Ethernet Port |
||
|
Physical Buttons |
WPS Button |
|
|
Reset Button |
||
|
Power Interfaces |
DC Jack |
|
|
Power |
Power Methods |
DC |
|
Power Input |
12V⎓1A |
|
|
Power Adapter in the Box |
Input: 100-240V~, 50/60Hz |
|
|
Output: 12V⎓1A |
||
|
Max Power Consumption (W) |
11.5W |
|
|
Idle Power Consumption (W) |
4.2W |
|
|
Reliability |
Environment |
Operating Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~104 ℉) |
|
Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉) |
||
|
Humidity: 10% ~ 90% non-condensing |
||
|
Storage Humidity: 5% ~ 95% non-condensing |
||
|
Certifications |
FCC, CE |
|
|
Mechanical |
Installation |
Desktop |
|
Dimension |
Φ110×154.5 mm |
|
|
Φ4.33×6.08 inches |
||
|
Product Weight |
360 g (12.7 oz.) |
|
|
What’s in the BOX |
M3000 |
|
|
Power Adapter |
||
|
Ethernet Cable |
||
|
Installation Guide |
||
|
Ordering Information |
Retail Package Weight |
1-Pack | EU / US: 680 g (23.99 oz.) |
|
2-Pack | EU / US: 1370 g (48.33 oz.) |
||
|
Retail Package Dimension |
1-Pack: 145×130×265 mm (5.71×5.12×10.43 inches) |
|
|
2-Pack: 330×130×265 mm (12.99×5.12×10.43 inches) |
||
Software Specifications
|
Wireless |
Wi-Fi Standards |
Wi-Fi 6 |
|
Max Wi-Fi Modulation |
1024-QAM |
|
|
Wi-Fi Efficiency |
OFDMA |
|
|
MU-MIMO |
||
|
BSS Color |
||
|
Max Capacity |
512 |
|
|
Recommended Client Upper Limit |
200 |
|
|
Max Wi-Fi Channel Width |
160 MHz |
|
|
Wi-Fi Security |
WPA/WPA2/WPA3 |
|
|
Guest Network |
2.4 GHz, 5 GHz |
|
|
WPS |
TRUE |
|
|
General |
Operation Modes |
Wi-Fi Router |
|
Access Point |
||
|
Range Extender |
||
|
WISP |
||
|
Client |
||
|
Mesh |
Cudy Mesh |
|
|
Mesh Backhaul |
Wireless Backhaul |
|
|
Wired Backhaul |
||
|
Multi-Band Backhaul |
TRUE |
|
|
WAN Mode |
DHCP |
|
|
Static IP |
||
|
PPPOE |
||
|
PPTP |
||
|
L2TP |
||
|
Network |
QoS |
Per-User Rate Limiting |
|
DHCP |
Address Reservation |
|
|
DHCP Client List |
||
|
Server |
||
|
IP Versions |
IPv4/IPv6 |
|
|
IPv6 Protocols |
Relay |
|
|
Dynamic (SLAAC/DHCPv6) |
||
|
Static (Fixed IP) |
||
|
Passthrough |
||
|
464XLAT |
||
|
MAP-E |
||
|
DS-Lite |
||
|
IPTV/VLAN |
Bridge |
|
|
Tag VLAN |
||
|
VoIP VLAN |
||
|
IPTV VLAN |
||
|
TTL Customization |
Extend |
|
|
Spoof |
||
|
Custom |
||
|
IGMP |
IGMP Proxy |
|
|
IGMP Snooping |
||
|
Forwarding |
Port Forwarding |
|
|
Port Triggering |
||
|
UPnP |
||
|
DMZ |
||
|
Firewall |
SPI Firewall |
|
|
DoS Protection |
||
|
Block PING |
||
|
Application Layer Gateway |
IPSec Passthrough, L2TP Passthrough, PPTP Passthrough, FTP Passthrough, TFTP Passthrough, H323 Passthrough, SIP Passthrough, RTSP Passthrough |
|
|
Utilities |
VPN Server |
WireGuard |
|
OpenVPN |
||
|
IPsec |
||
|
Zerotier |
||
|
PPTP |
||
|
L2TP |
||
|
VPN Client |
WireGuard |
|
|
OpenVPN |
||
|
IPsec |
||
|
Zerotier |
||
|
PPTP |
||
|
L2TP |
||
|
DNS Options |
DNS over TLS |
|
|
Manual DNS |
||
|
Rebind Protection |
||
|
Override Clients' DNS |
||
|
DNS over TLS Providers |
Cloudflare |
|
|
|
||
|
Quad9 |
||
|
Custom |
||
|
Wake on LAN |
TRUE |
|
|
Online Detection |
TRUE |
|
|
Management |
Parental Controls |
Profiles Settings |
|
Offline Time |
||
|
Online Time |
||
|
Pause the Internet |
||
|
Web Filter |
||
|
All Devices Management |
Wi-Fi Time Schedule |
|
|
MAC Filter |
||
|
IP/MAC Binding |
||
|
Per-Devices Management |
Internet On/Off |
|
|
VPN On/Off |
||
|
Online Time Schedule |
||
|
Device Rename |
||
|
Content Management |
Domain Filter |
|
|
IP Filter |
||
|
System |
LED Control |
TRUE |
|
Local Control Method |
Config Web Page |
|
|
App Control |
||
|
Remote Control Method |
Config Page via HTTPS |
|
|
App Control |
||
|
TR069/TR098/TR111/TR143/TR181 |
||
|
Firmware Upgrade |
Local Update |
|
|
App (Over the Air) |
||
|
Online Update |
||
|
Reliability |
Timed Reboot |
|
|
Backup and Restore |
||
|
Diagnostic Tools |
Diagnosis |
|
|
Ping |
||
|
Traceroute |
||
|
NSLookup |
||
|
System Log |
||
|
Languages |
English, Bengali, Catalan, Czech, German, Greek, Spanish, French, Hebrew, Croatian, Hungarian, Italian, Japanese, Khmer, Korean, Dutch, Norwegian, Polish, Portuguese, Romanian, Russian, Slovak, Swedish, Thai, Turkish, Ukrainian, Vietnamese, Simplified Chinese, Traditional Chinese |
|
|
Dashboard |
Panel |
Internet Status, Mesh Status, Devices Management, WAN Status, LAN Status, WISP Status, Wi-Fi Status, VPN Status, DHCP Server Status, System Version |
|
Charts |
Mesh Topology, Internet Speed, WISP Speed, Wi-Fi Speed |
What's in the box
- 2 x AX3000(M3000) Wi-Fi Mesh Node
- 2 x Power Adapter
- 1 x Ethernet Cable
- 1 x Installation Guide
